Denon AVR-S730H User Manual

Speaker configuration and “Amp Assign” settings
This unit has a built-in 7-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by changing
the “Amp Assign” settings to suit the application, such as 7.1-channel systems and 2-channel systems for multi-zone playback. (v p. 170)
Perform “Amp Assign” settings to suit the number of rooms and speaker configuration to be installed. (v p. 170)
Playback speaker and zone
“Amp Assign” settings
Connection
page
MAIN ZONE ZONE2
5.1-channel Not used Can be set in all “Amp Assign” modes. 39
7.1-channel (surround back) Not used Surround Back 40
7.1-channel (front height) Not used Front Height 41
7.1-channel (top front) Not used Top Front 42
7.1-channel (top middle) Not used Top Middle 43
7.1-channel (front Dolby Atmos Enabled speaker) Not used Front Dolby 44
7.1-channel (surround Dolby Atmos Enabled speaker) Not used Surround Dolby 45
5.1-channel
2-channel
(Speaker out)
ZONE2 (Default) 46
0
The sound mode that can be selected varies according to the speaker configuration. See “Sound modes and channel output” (v p. 227) for the sound modes that are
supported.
Contents Connections Playback Settings Tips Appendix
38
Front panel Display Rear panel Remote Index

Denon AVR-S730H Specifications

General

Channels	7.2
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive)	110W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive)	165W
HDMI Inputs	6
HDMI Outputs	1
Dolby Atmos	Yes
DTS:X	Yes
DTS Virtual:X	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Multi-room	Yes
4K Ultra HD Pass-through	Yes
HDR Support	Yes (HDR10, Dolby Vision, HLG)
Auto Speaker Calibration	Audyssey MultEQ
AirPlay	Yes (AirPlay 2)
Internet Radio	Yes
Phono Input	No
Ethernet Port	Yes
Power Output per Channel	75W (8 ohm, 20Hz-20kHz, 0.08% 2ch Drive)
USB Input	1 (Front)
