Denon AVR-S900W Quick Start Guide

2
What’s In the Box
Quick Start Guide FM indoor antenna
Owner’s Manual AM loop antenna
Safety Instructions Remote control
unit
Notes on radio R03/AAA batteries
Warranty
(for North America
model only)
Sound calibration
microphone
Cable labels Sound calibration
microphone stand
Receiver
The supplied Sound calibration microphone stand is
convenient for use when performing Speaker Calibration.
Using your own tripod or the supplied Sound calibration
microphone stand enables settings to be automatically
configured to the optimum listening environment, providing
exceptionally high performance.
• When connecting this unit to a device that is compatible
with the Deep Color, 4K and ARC functions, use an
“Ethernet-compatible High Speed HDMI cable” that
comes with the HDMI logo.
• These drawings are for illustrative purposes only and may
not represent the actual product(s).

Denon AVR-S900W Specifications

General

Channels	7.2
HDMI Inputs	8
HDMI Outputs	2
Wi-Fi	Yes
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby Atmos	Yes
DTS:X	No
HDMI Pass-Through	Yes
Input Impedance	47 kOhm
Input Sensitivity	200 mV
THD at rated output	0.08%
Signal-To-Noise Ratio	98 dB
DAC Resolution	24-bit / 192kHz
HDMI Switching	Yes
AirPlay	Yes
DLNA	Yes
Dimensions	17.1 x 6.6 x 13.3 inches
Power Output	90 W
Response Bandwidth	10Hz-100kHz
Output Impedance / Channel	6 Ohm
Inputs	HDMI
Outputs	HDMI
Supported Audio Formats	MP3, WMA, AAC, FLAC, WAV
Supported Video Formats	4K
Output Power / Channel	90W (8 ohms, 20Hz-20kHz, 0.08% THD)
