0
When performing Audyssey
®
Setup for the first time, the measurement data
is automatically saved to “Preset 1” of “Speaker Preset”.
0
If Audyssey
®
Setup has already been performed, the following “Speaker
Preset” selection screen is displayed.
.
Audyssey Setup
Select which Preset to use. Preset 1 is already used, selecting
Preset 1 now will overwrite the previously stored setting.
Preset 2
Preset 1
Analyzing room data
0%
Back
0
See “Speaker Preset” for detailed information on the Speaker Preset
function. (v p. 200)
13
Select “Details” and press ENTER to verify the
measurement results.
0
Subwoofers may measure a greater reported distance than the
actual distance due to added electrical delay common in
subwoofers.
NOTE
0
Do not enable new speakers in speaker configuration menu after Audyssey
®
Setup. If it is changed, run Audyssey
®
Setup again in order to configure the
optimum equalizer settings.
Contents
Connections Playback Settings Tips Appendix
187
Front panel Display Rear panel Remote Index

Denon AVR-S960H Specifications

General

Display	VFL
HDCP version	2.3
Apple docking	No
Product color	Black
Audio decoders	DTS Virtual:X, DTS:X
Volume control	Rotary
Receiver type	stereo
Frequency range	10 - 100000 Hz
Input sensitivity	200 mV
Audio output channels	7.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	95 W
Connectivity technology	Wired & Wireless
Speakers connectivity type	RCA
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	460 W
Package weight	11500 g
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
HDMI in	7
Audio (L/R) in	4
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
3D	-
Package depth	429 mm
Package width	520 mm
Package height	243 mm

Weight and Dimensions

Depth	330 mm
Width	434 mm
Height	167 mm
Weight	9500 g
