Denon AVR-X1300W Service Manual

NO
NO
NO
Is IC601(TOP268VG) dam-
aged?
Is D6001/ D6002 / D6003 /
D6004 damaged?
Repair the short circuited area
on the PCB.
Replace the damaged part.
Replace the damaged part.
Is the fuse (F6001) functioning
properly?
Are there any short circuits
caused by the soldering on
the PCB?
Are any parts damaged?
Replace the IC601(TOP268VG)
and D6001/ D6002 / D6003 /
D6004.
DC5.2V is not output.
*OPTION
*OPTION
E3,K:100UF/200V E1C,E2 :100UF/400V
OPTION
*OPTION
*OPTION
VXCFD
S
S S S S S
R6004 330K
C6005
OPEN
C6006 O PEN C6007 50V/0.1uF
C6009
50V/0.22uF
R6006
1M(1608)
D6006 1N4007
D6005 1N4007
D6001 1N4007
D6002 1N4007
D6003 1N4007
D6004 1N4007
CX602
OPEN
R6013
22K(1608)
R6014
1K(1608)
R6012
270K
R6010
1M(0.2W)
R6008
2.2M(0.2W)
ZD608
Z39V
ZD609
Z39V
ZD610
Z39V
R6009
2.2M(0.2W)
ZD617
Z22V
ZD616
Z22V
ZD615
Z22V
ZD614
Z22V
ZD613
Z22V
ZD612
Z22V
ZD611
Z22V
C6011
1KV/1000pF (SM D)
R6015
6.8(0.2W)
C6013
47/25V(NXA)
R6011
10(1608)
D6012
1N4007
ZD620
Z39V
C6012
0.1uF(1608)
D6007
1N4007
ZD618
Z27V
C6008
50V/10UF(NXA)
D6008
1N4007
C6014 0.1uF(1608)
C6015
4.7uF(1608)
C6017
OPEN
C6018 5600uF/6.3V(NXA)
C6019 5600uF/6.3V(NXA)
C6023
250V/2200pF
C6024 0.1uF(1608)
R6017
3.3K(0 .2W)
R6016
56(0.2W)
5.6K(0 .2W)
C6002 250V/0.01uF
C6003
250V/0.01uF
R6026
OPEN(1608)
C6025 OPEN(1608)
C6004
200V/100uF
R6031
1M(2125)
R6032
1M(2125)
R6033
1M(2125)
43
2 1
IC602
ZD621
Z7.5V
J6002
JUMPER
J6003
JUMPER
D
G
S
Q6002
INK0010AC1
3
2
1
D6013
RBQ30T 65A
C6026
1KV/47pF
C6027
OPEN
C6028
OPEN
R6034
OPEN
12346
7
8 10
9 11 1 2
IC601
CVIT OP268VG
J6001
OPEN
ZD601
Z12V
1
2
3
4
5
6
7
8
9
10
11
12
13
14
T6001
VLT9 Z132ZW
BK603
CMD1A629
BRACKE T
A
B
C
After primary side rectification
(Caution: High voltage, electric shock)
Primary drain
(Caution: High voltage, electric shock)
After secondary rectifications
Operation waveform for each part
A B C
A B C
SMPS unit
(Unloaded)
Set
YES
YES YES
YES
YES
6. SMPS
71
Caution in
servicing
Electrical Mechanical Repair Information Updating

Denon AVR-X1300W Specifications

General

Display	-
Product color	Black
Audio decoders	DSD, Dolby TrueHD
Audio amplifier	Yes
Multi-Zone quantity	2
Apple docking compatibility	Not supported
Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (20-20KHz@8 Ohm)	145 W
Audio formats supported	AAC, AIFF, ALAC, FLAC, MP3, WAV, WMA
HDMI in	6
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Supported video modes	2160p
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	430 W
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Connectivity technology	Wired
Speakers connectivity type	3.5mm
Optical drive included	No

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	215 mm
Weight	8500 g
