4. Protection Pass Mode 5. Network Initialization Mode
4.1. Actions
• This mode allows the power to be turned on without activating protections.
• This mode functions in the same way as normal power-on, except that protections are not activated.
• When using the protection pass mode, do not connect speakers to the speaker terminals.
4.2. Operations
AVR-X1600H
• While holding down buttons "
TUNER PRESET CH +
", "
ZONE2 SOURCE
" and "
STATUS
" simultane-
ously, press the power button to turn on the power.
AVR-S750H
• While holding down buttons "
ZONE2 SOURCE
", "
TUNER PRESET CH +
" and "
TUNE +
" simultane-
ously, press the power button to turn on the power.
The device returns to the normal display message after the following is displayed.
Protection Pass
This is displayed for 5 seconds before returning to the normal display.
5.1. Actions
The following items are initialized.
(1) Network setup
(2) Friendly Name
(3) Auto Update setting
(4) Allow Update setting
(5) Time Zone setting
(6) Queue list
(7) Internet Radio recently played station
(8) Quick Select playback station
(9) AirPlay Password
(10) Bluetooth Pairing History
5.2. Operations
AVR-X1600H
• When the power is on and the input source is HEOS Music, press and hold the "
TUNERPRESET CH
+
" and "
ZONE2 ON/OFF
" buttons for more than 3 seconds.
AVR-S750H
• When the power is on and the input source is HEOS Music, press and hold the "
ZONE2 SOURCE
" and
"
ZONE2 ON/OFF
" buttons for more than 3 seconds.
Initializing Display
Network Reset...
Complete Display
Completed
This is displayed for 5 seconds before returning to the normal display.
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
127

Denon AVR-X1600H Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	4 - 16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	6
AC (power) in	Yes
Composite video in	2
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	Clamp terminals
Display	-
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
AM band range	520 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	440 W
Operating temperature (T-T)	5 - 35 °C
Package weight	10600 g
Certification	CE
Package depth	435 mm
Package width	523 mm
Package height	232 mm

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	215 mm
Weight	8600 g
