Denon AVR-X1600H Service Manual

DIAGNOSTIC PATH DIAGRAM
g.A01
NJU72750AV
InA /B 7
InA /B 6
InA /B 4
InA /B 3
InA /B 5
InA /B 2
InA /B 1
* LO G IC C O NT RO L H IGH LE V EL INPUT VO L T AG E ( M IN: + 2.5 V / MAX : V +)
SELECT IC
OU TB3
OU TB2
OU TB1
OU TA3
OU TA2
OU TA1
7in3out Ma trix-Sw itch
V-:-7.5V
V+ :+ 7.5 V
NJU72750AV
InA /B 7
InA /B 6
InA /B 5
InA /B 4
InA /B 3
InA /B 2
InA /B 1
* LOGIC CONT RO L H IGH LE V E L INPUT V OL T A G E ( M IN: + 2.5 V / MAX : V + )
V+ :+ 7.5 V
V-:-7.5V
7in3out Ma trix-Switch
OU TA1
OU TA2
OU TA3
OU TB1
OU TB2
OU TB3
SELECT IC
AUDIO IN
CEN
FR
FL
+
-
-
+
-
+
+
-
-
+
SL
SR
SPK OU T
PRE OU T
TU N E R
AD _FL
AD _FR
TO D IGITA L
AUDIO BL OCK
D A_FL
D A_FR
D A_CEN
D A_SW
D A_SL
D A_SR
CBL/S A T
MIC ( AU TO S ET UP )
Z2_N E T _ LR
SW 1
MU T E
AUDY SSEY
MED IA P L A YER
P-AMP
ZONE2
AVRX 1600H E 3 ONLY
MUT E
D A_FL
D A_FR
D A_CEN
D A_SW
D A_SL
D A_SR
D A_SBL
D A_SBR
AN A _ FL
AN A _ FR
H / P L
GND
H / P R
H /P OU T
+
-
-
+
SBL
SBR
BD 3812F
VOL IC
SW 2
D A_SBL
D A_SBR
(FL -H /FL-B/ B I-AMP -FL/ZONE-FL)
(FR -H /FR-B/B I-AMP-FR / ZO N E-FR )
32.768kH z
FM /A M
ATT.
LE G O _ AD C _ R
NJU72343V
VOLUME IC
LE G O _ AD C _ L
ATT.
ATT.
ATT.
PH ON O
V+ :+ 7.5 V
V-:-7.5V
* LO G IC C O NT RO L H IGH LEVEL INPUT VO L T AG E ( M IN: + 2.5V / MAX : V +)
VCC:D A+ 5V
-7 .0dB
-8 .5dB
D NMIX _ L R
MAIN ZO NE
LEGO
ZON E2
D A0 7
D A0 8
D A0 1
D A0 2
D A0 3
D A0 4
D A0 5
D A0 6
D A0 1
D A0 2
D A0 3
D A0 4
D A0 5
D A0 6
D A0 7
D A0 8
AVRS750H /X1600H ANALOG AUD IO BLOCK
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
132

Denon AVR-X1600H Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	4 - 16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	6
AC (power) in	Yes
Composite video in	2
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	Clamp terminals
Display	-
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
AM band range	520 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	440 W
Operating temperature (T-T)	5 - 35 °C
Package weight	10600 g
Certification	CE
Package depth	435 mm
Package width	523 mm
Package height	232 mm

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	215 mm
Weight	8600 g
