Denon AVR-X1600H Service Manual

BLOCK DIAGRAM
ANALOG AUDIO DIAGRAM
NJU72750AV
InA /B7
InA /B6
InA /B4
InA /B3
InA /B5
InA /B2
InA /B1
* LO GIC CON T RO L H IGH LEVEL INP U T VO LT AG E ( M IN: + 2.5V / MAX : V +)
SELECT IC
OU TB 3
OU TB 2
OU TB 1
OU TA 3
OU TA 2
OU TA 1
7in3out Ma trix-Sw itch
V-:-7 .5V
V+ :+ 7.5V
NJU72750AV
InA /B7
InA /B6
InA /B5
InA /B4
InA /B3
InA /B2
InA /B1
* LO G IC CONT RO L H IG H LEVEL INPUT V OL T AG E(M IN : + 2.5 V / MAX : V + )
V+ :+ 7.5V
V-:-7 .5V
7in3out Ma trix-Sw itch
OU TA 1
OU TA 2
OU TA 3
OU TB 1
OU TB 2
OU TB 3
SELECT IC
AUDIO IN
CEN
FR
FL
+
-
-
+
-
+
+
-
-
+
SL
SR
SPK OUT
PRE OUT
TU NER
AD _FL
AD _FR
TO D IGITAL
AUDIO BLOCK
D A _FL
D A _FR
D A _C EN
D A _SW
D A _SL
D A _SR
CBL/S A T
MIC (A UT O S ET UP)
Z2_N E T _ L R
SW 1
MUTE
AUDY SSEY
MED IA PLAY ER
P-AMP
ZONE2
AVRX 1600H E3 ONL Y
MUT E
D A _FL
D A _FR
D A _CEN
D A _SW
D A _SL
D A _SR
D A _SBL
D A _SBR
ANA _ F L
ANA _ F R
H / P L
GND
H / P R
H /P OU T
+
-
-
+
SBL
SBR
BD 3812F
VOL IC
SW 2
D A _SBL
D A _SBR
(FL -H /FL-B/ B I-AMP -FL/Z ONE-FL)
(FR -H /FR-B/B I-AMP -FR/ZO NE-FR)
32.768kH z
FM /A M
ATT.
LE G O _ A D C_ R
NJU72343V
VOLUME IC
LE G O _ A D C_ L
ATT.
ATT.
ATT.
PH ONO
V+ :+ 7.5V
V-:-7 .5V
* LO GIC CON T RO L HIGH LE V EL INPU T VO L TAGE(MIN : + 2.5 V / MAX : V + )
VCC:D A+ 5V
-7.0dB
-8.5dB
D NMIX _ L R
MAIN ZO NE
LEGO
ZON E2
D A0 7
D A0 8
D A0 1
D A0 2
D A0 3
D A0 4
D A0 5
D A0 6
D A0 1
D A0 2
D A0 3
D A0 4
D A0 5
D A0 6
D A0 7
D A0 8
AVRS750H /X1600H ANALOG AUDIO BLOCK
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
39

Denon AVR-X1600H Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	4 - 16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	6
AC (power) in	Yes
Composite video in	2
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	Clamp terminals
Display	-
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
AM band range	520 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	440 W
Operating temperature (T-T)	5 - 35 °C
Package weight	10600 g
Certification	CE
Package depth	435 mm
Package width	523 mm
Package height	232 mm

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	215 mm
Weight	8600 g
