Denon AVR-X1600H Service Manual

FIRMWARE UPDATE PROCEDURE
1. Items necessary for update
Items necessary for update are as follows.
Update Type Needed Part for Update Requirement
Offered / not Offered
Standard Service Equipment
Not offered by D&M
Purchase from D&M Article code Download from SDI
Via USB
USB ash drive (USB 2.0 : Min 1GB)
• We recommend a USB memory device
that has an LED installed.
Formatting FAT16 or FAT 32 X - "Table 1" or "Table 2"
Via OTA
Internet Connection by Broadband Circuit - X - -
Modem - X - -
Router - X - -
Ethernet cable
(CAT-5 or greater is recommended)
- X - -
Table 1
Update download le when the DIGITAL PCB or network module is replaced
Model Name Model Area Download from SDI
AVR-X1600H
AVR-S750H
ALL avr_40.prod.update.factory.xxxx.zip
Table 2
Update download le when the rmware is updated (Two les, "HW component" and "LEGO component")
Model Name Model Area
Download from SDI
For HW component For LEGO component
AVR-X1600HE3 North America (E3) Product ID : 000101150100 DPMS_AVR-X1600HE3_LEGO_xxxx.zip
heos_40.prod_x.xxx.xx.zip
AVR-X1600HE2 Europe (E2) Product ID : 000101150200 DPMS_AVR-X1600HE2_LEGO_xxxx.zip
AVR-X1600HJP Japan (JP) Product ID : 000101150400 DPMS_AVR-X1600HJP_LEGO_xxxx.zip
AVR-X1600HE1C China (E1C) Product ID : 000101150500 DPMS_AVR-X1600HE1C_LEGO_xxxx.zip
AVR-S750HE3 North America (E3) Product ID : 000101150700 DPMS_AVR-S750HE3_LEGO_xxxx.zip
AVR-S750HE2 Europe (E2) Product ID : 000101150900 DPMS_AVR-S750HE2_LEGO_xxxx.zip
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
154

Denon AVR-X1600H Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	4 - 16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	6
AC (power) in	Yes
Composite video in	2
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	Clamp terminals
Display	-
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
AM band range	520 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	440 W
Operating temperature (T-T)	5 - 35 °C
Package weight	10600 g
Certification	CE
Package depth	435 mm
Package width	523 mm
Package height	232 mm

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	215 mm
Weight	8600 g
