Denon AVR-X1600H Service Manual

2. Analog video
MONITOR OUT (CVBS) output NG
Is a signal being output from the video ampli-
er?
Output V : [IC881 : 8pin]
Check the cable between the unit and the moni-
tor or check the monitor.
The power supply circuit is faulty.
Does the signal input to the video amplier?
(for SAT/CBL function)
VIN3 : [IC881 : 5pin]
Check the settings of each IC. Are the following
voltages set?
SW2 : [IC881_4pin] : 3.3V
MUTE : [IC881_6pin] : 3.3V
The circuit around [IC881] is faulty.
The CPU [IC751] is faulty.
Check the pattern between [JK881] and [IC881],
and then check the Blu-ray/DVD player or the
cable between the unit and the Blu-ray/DVD
player.
Is the power voltage being output correctly?
CEC5V : [C8814 : +side]
YES YES
YES
YES
NO
NO NO
NO
MP_CUP13021Z_A
