Denon AVR-X1600H Service Manual

3. Starting detecting the point of failure
Check item(3.1.).
Check the power supply status and communication status with the CPU of each device.
Start in HDMI Diagnostics mode and follow the procedures below.
Start in HDMI Diagnostics mode
While the power is on, hold down buttons "
TUNER PRESET CH -
" and "
ZONE2 SOURCE
" for at least 3
seconds.
HDMI DIAGNOSTICS
"HDMI DIAGNOSTICS" is displayed.
When the mode has switched, start Hardware Check.
HardwareCheck...
Display when an Error is detected.
Err: H1-XX
Alternating display.
Contact support
Check the Error Code table items.
Error Code table
Error Code Check item No. Description
H1-01 Check item (3-1.1.) Communication Error with HDMI Rx/Tx [IC721 : MN864788]
H1-02 Check item (3-2.1.) Communication Error with HDMI SW [IC701 : MN864787]
H1-07 Check item (3-3.1.) Communication Error with OSD [IC731 : ADV7623]
H1-08 Check item (3-5.1.) Communication Error with DSP [IC781 : CS49844A]
H1-12 Check item (3-6.1.) Communication Error with DIR [IC761 : PCM9211]
H1-15 Check item (3-4.1.) Communication Error with OSD ROM [IC732 : BY25Q32BSSIG/BY25Q64ASSIG]
H1-16 Check item (3-7.1.) Communication Error with ARC IC [IC724 : Sil9437]
Display when an Error is not detected.
1 Auto Test
Cancel the mode, and proceed to check item (3.2.).
Canceling the selected mode
Press the power button to exit off the power.
Before Servicing
This Unit
Electrical Mechanical Repair Information Updating
85

Denon AVR-X1600H Specifications

General

Receiver type	Surround
Frequency range	10 - 100000 Hz
Output impedance	4 - 16 Ω
Input sensitivity	200 mV
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	98 dB
Power output per channel (1KHz@6 Ohm)	145 W
Power output per channel (20-20KHz@8 Ohm)	80 W
HDMI in	6
AC (power) in	Yes
Composite video in	2
Digital audio coaxial in	0
Ethernet LAN (RJ-45) ports	1
Connectivity technology	Wired & Wireless
Speakers connectivity type	Clamp terminals
Display	-
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS:X, Dolby Atmos, Dolby Surround, Dolby TrueHD
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
AM band range	520 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Internet radio services supported	Amazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	440 W
Operating temperature (T-T)	5 - 35 °C
Package weight	10600 g
Certification	CE
Package depth	435 mm
Package width	523 mm
Package height	232 mm

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	215 mm
Weight	8600 g
