Denon AVR-X3700H User Manual

Speaker configuration and “Amp Assign” settings
This unit has a built-in 9-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by changing
the “Amp Assign” settings to suit the application, such as 7.1-channel systems, bi-amp connections and 2-channel systems for multi-zone playback.
(v p. 215)
Perform “Amp Assign” settings to suit the number of rooms and speaker configuration to be installed. (v p. 215)
Playback speaker in each zone
“Amp Assign” settings
Connection
page
MAIN ZONE ZONE2
5.1-channel playback
2-channel (Pre-out)
Can be set in all “Amp Assign” modes. 43
7.1-channel playback 7.1ch + ZONE2 (Default) 44
9.1-channel playback 9.1ch 48
11.1-channel playback 11.1ch 55
7.1-channel playback (bi-amp connection of front
speakers)
7.1ch (Bi-Amp) 59
Second front speakers 7.1ch + Front B 60
7.1-channel playback 2-channel
(Speaker out)
7.1ch + ZONE2 (Default) 61
5.1-channel playback (bi-amp connection of front
speakers)
2-channel
(Speaker out)
5.1ch (Bi-Amp) + ZONE2 62
9.1-channel playback (using this unit as a pre amplifier) Not used Pre Amplifier 63
The sound mode that can be selected varies according to the speaker configuration.
The following pages provide basic connection examples.
Contents
Connections Playback Settings Tips Appendix
41
Front panel Display Rear panel Remote Index

Denon AVR-X3700H Specifications

General

Channels	9.2
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
4K/120Hz Pass-through	Yes
8K/60Hz Pass-through	Yes
Wi-Fi	Yes
Bluetooth	Yes
HEOS Built-in	Yes
Impedance	4 - 16 ohms
Frequency Response	10 Hz - 100 kHz
Input Sensitivity	200 mV
HDCP Support	2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Audio Return Channel (ARC)	eARC
Phono Input	Yes
Ethernet	Yes
USB	Yes
AM/FM Tuner	Yes
Power Output per Channel	105W (8 ohms, 20 Hz - 20 kHz, THD 0.08%, 2ch driven)
Signal-to-Noise Ratio	100 dB
Video Upscaling	Yes, up to 8K
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	12.5 kg
