Sound modes and channel output
S This indicates the audio output channels or surround parameters that can be set.
D This indicates the audio output channels. The output channels depend on the settings of “Speaker Config.”. (v
p. 91)
.
Sound mode
Channel output
Front L/R Center Surround L/R Subwoofer
Direct (2-channel)
S Dz
Direct (Multi-channel)
SDDD
Stereo
S D
Multi Ch In
SDDD
Dolby Pro Logic g SDDD
DTS Neo:6
SDDD
Dolby Digital
SDDD
Dolby Digital Plus
SDDD
Dolby TrueHD
SDDD
DTS Surround
SDDD
DTS 96/24
SDDD
DTS-HD
SDDD
DTS Express
SDDD
Multi Ch Stereo
SDDD
Virtual
S D
z
Audio is output when “Subwoofer Mode” in the menu is set to “LFE+Main”. (v p. 94)
Contents
Connections Playback Settings Tips Appendix
122
Front panel Display Rear panel Remote Index

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
