Listening to FM/AM broadcasts
1
Connect the antenna. (“Connecting an FM/AM
antenna” (v p. 34))
2
Use FM or AM to switch the input source to “FM” or
“AM”.
G TV screen H
.
01
Tuner
FM 87.5MHz
Tune Preset
-
+
TUNE
Option
OPTION
AUTO
CH d/f
.
01 FM 87.50MHz
GDisplay of this unitH
3
Press MODE to select the tune mode, then press
ENTER.
AUTO
(Default) :
Automatically search for and tune to a
receivable radio station.
MANUAL:
Manually change the frequency one
step at a time each time the button is
pressed.
4
Press TUNE + or TUNE - to select the station you want
listen to.
Scanning is performed until it finds an available radio station. When
it finds a radio station, it stops the scan automatically and tunes in.
0
In “AUTO” mode, you cannot tune in to radio stations if the reception is not good.
If this is the case, then use the “MANUAL” mode to tune in.
0
You can also scan the broadcast station by pressing TUNE + or TUNE - on the
unit.
Operation buttons Function
CH/PAGE d f
Selects preset radio stations
MODE Switching tune mode
MEMORY Register presets
TUNE +, - Selects the radio station (up/down)
Contents Connections Playback Settings Tips Appendix
48
Front panel Display Rear panel Remote Index

Other manuals for Denon AVR-X540BT

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X540BT and is the answer not in the manual?

Denon AVR-X540BT Specifications

General IconGeneral
Channels5.2
HDMI Inputs5
HDMI Outputs1
BluetoothYes
4K Ultra HD Pass-throughYes
Dolby TrueHDYes
DTS-HD Master AudioYes
Auto Speaker CalibrationNo
Number of Power Amps5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)140 W
Composite In2
Composite Out1
Digital In: Optical2
Analog In2
Speaker Terminal: ScrewYes
FM Tuner with RDSYes
3D Signal Pass-ThroughYes
Audio Return ChannelYes
HDMI Standby Pass-ThroughYes
CECYes
Auto Speaker Setup by MicrophoneNo
Dimensions (W x H x D)434 x 151 x 319 mm
Weight7.5 kg
Total Harmonic Distortion0.08 %
Input Sensitivity/Impedance200 mV / 47 kΩ
Signal-to-Noise Ratio98 dB
Ethernet PortNo
Wi-FiNo
Power Output per Channel70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response10Hz - 100kHz
Supported Audio FormatsMP3, WMA, AAC
