Denon AVR-X540BT User Manual

o
Operations accessible through the option
menu
0
“RDS search” (v p. 49)
0
“PTY search” (v p. 50)
0
“TP search” (v
p. 51)
0
“Radio Text” (v p. 51)
0
“Tuning in to stations and presetting them automatically (Auto
Preset)” (v p. 52)
0
“Skipping preset broadcast stations (Preset Skip)” (v p. 54)
0
“Adjusting the tone (Tone)” (v p. 57)
0
“Displaying your desired video during audio playback (Video
Select)” (v
p. 59)
RDS search
RDS (works only on the FM band) is a broadcasting service which allows
a station to send additional information along with the regular radio
program signal.
Use this function to automatically tune to FM stations that provide the RDS
service.
Note that the RDS function only works when receiving RDS compatible
stations.
1
Press FM to switch the input source to “Tuner”.
2
Press OPTION.
The option menu screen is displayed.
3
Use ui to select “RDS Search”, then press ENTER.
4
Press ENTER.
The search for RDS stations begins automatically.
Contents Connections Playback Settings Tips Appendix
49
Front panel Display Rear panel Remote Index

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
