Pass Source
Sets the HDMI connector that inputs HDMI signals when in standby.
Last
(Default):
The most recently used input source will go
into standby mode.
CBL/SAT /
DVD/Blu-ray /
Game / Media Player:
Pass through the selected input source.
0
“Pass Source” can be set when “HDMI PassThrough” is set to “On” or “HDMI
Control” is set to “On”. (“HDMI PassThrough” (v
p. 80), “HDMI
Control” (v
p. 81))
HDMI Control
You can link operations with devices connected to HDMI and compatible
with HDMI Control.
On: Use HDMI control function.
Off
(Default):
Do not use HDMI control function.
0
Please consult the operating instructions for each connected device to check the
settings.
0
Refer to “HDMI control function” for more information about the HDMI control
function. (v p. 64)
NOTE
0
If the “HDMI Control” settings have been changed, always reset the power to
connected devices after the change.
Contents Connections Playback Settings Tips Appendix
81
Front panel Display Rear panel Remote Index

Denon AVR-X540BT Specifications

General

Channels	5.2
HDMI Inputs	5
HDMI Outputs	1
Bluetooth	Yes
4K Ultra HD Pass-through	Yes
Dolby TrueHD	Yes
DTS-HD Master Audio	Yes
Auto Speaker Calibration	No
Number of Power Amps	5
Output Power (6 ohm, 1 kHz, 0.7% 2ch Drive)	90 W
Output Power (6 ohm, 1 kHz, 10% 1ch Drive)	140 W
Composite In	2
Composite Out	1
Digital In: Optical	2
Analog In	2
Speaker Terminal: Screw	Yes
FM Tuner with RDS	Yes
3D Signal Pass-Through	Yes
Audio Return Channel	Yes
HDMI Standby Pass-Through	Yes
CEC	Yes
Auto Speaker Setup by Microphone	No
Dimensions (W x H x D)	434 x 151 x 319 mm
Weight	7.5 kg
Total Harmonic Distortion	0.08 %
Input Sensitivity/Impedance	200 mV / 47 kΩ
Signal-to-Noise Ratio	98 dB
Ethernet Port	No
Wi-Fi	No
Power Output per Channel	70W (8 ohms, 20Hz - 20kHz, 0.08% THD)
Frequency Response	10Hz - 100kHz
Supported Audio Formats	MP3, WMA, AAC
