Denon AVR-X6300H User Manual

Upgrade
7
Accessories
8
Inserting the batteries
9
Operating range of the remote control unit
9
Features
10
High quality sound
10
High performance
12
Easy operation
16
Part names and functions
17
Front panel
17
Display
21
Rear panel
23
Remote control unit
27
Connections
Connecting speakers
31
Speaker installation
31
Speaker connection
40
Speaker configuration and “Amp Assign” settings
44
Connecting a TV
73
Connection 1 : TV equipped with an HDMI connector and
compatible with the ARC (Audio Return Channel)
74
Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel)
75
Connection 3 : TV equipped without an HDMI connector
76
Connecting a playback device
77
Connecting a set-top box (Satellite tuner/cable TV)
78
Connecting a DVD player or Blu-ray Disc player
79
Connecting a Blu-ray Disc player compatible with the Denon Link
HD function
80
Connecting a video camcorder or game console
81
Connecting a turntable
82
Connecting a USB memory device to the USB port
83
Connecting an FM/AM antenna
84
Connecting to a home network (LAN)
86
Wired LAN
86
Wireless LAN
87
Connecting an external control device
88
REMOTE CONTROL jacks
88
TRIGGER OUT jacks
89
Connecting the power cord
90
Playback
Basic operation
92
Turning the power on
92
Selecting the input source
92
Adjusting the volume
93
Turning off the sound temporarily (Muting)
93
Playback a DVD player/Blu-ray Disc player
93
Contents Connections Playback Settings Tips Appendix
Contents
2
Front panel Display Rear panel Remote Index

Denon AVR-X6300H Specifications

General

Receiver type	Surround
Frequency range	10 - 10000 Hz
Input sensitivity	200 mV
Pre-out connectivity	Yes
Audio output channels	11.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	175 W
Power output per channel (20-20KHz@8 Ohm)	140 W
HDMI in	8
Composite video in	4
Ethernet LAN (RJ-45) ports	1
Component video (YPbPr/YCbCr) in	2
Headphone connectivity	3.5 mm
Multichannel audio output type	RCA
Display	-
Audio decoders	DTS-HD Master Audio, Dolby Surround, Dolby TrueHD
Connector contacts plating	Gold
Apple docking compatibility	Not supported
Connectivity technology	Wired & Wireless
Speakers connectivity type	3.5mm
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range	520 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Internet radio services supported	Napster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
Optical drive included	No
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.1 W
Power consumption (typical)	750 W
Supported video modes	2160p

Weight and Dimensions

Depth	339 mm
Width	434 mm
Height	235 mm
Weight	14500 g
