Denon AVR-X8500H Upgrade Information

3
2The HDMI input 7 will be assigned to “AUX2 (8K)” as a default input source. 
NOTE
• Along with the above, the unassigned HDMI input connector is changed from HDMI 7 to HDMI 6.
2The following information will be displayed when “HDMI Signal Info.” or
“HDMI Monitor 1 / HDMI Monitor 2” is selected in the setup menu.
8K signal / HDR10+ / Dynamic HDR / ALLM (All Low Latency Mode) /
VRR (Variable Refresh Rate) / QMS (Quick Media Switching) /
QFT (Quick Frame Transport) / eARC (Enhanced Audio Return Channel)
2The “4K Signal Format” in the setup menu will be renamed as “4K/8K Signal
Format” and “8K Enhanced” mode will be newly added. Select “8K Enhanced”
mode to allow 8K or 4K 120Hz pass-through.
NOTE
• The default setting after the upgrade is changed from “Standard” to “Enhanced”.
1.SPK610-611_RMF_ENG_00A_210408.indd 31.SPK610-611_RMF_ENG_00A_210408.indd 3 2021/04/08 11:19:262021/04/08 11:19:26
PrintingColor:Black

Denon AVR-X8500H Specifications

General

Channels	13.2
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Frequency Response	10Hz-100kHz (+1, -3dB)
HDMI Inputs	8 (1 front)
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
HEOS Multi-room	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Impedance	4-16 ohms
HDR Compatibility	HDR10, Dolby Vision, HLG
Audio Return Channel (ARC)	Yes
Digital Audio Inputs	2 Optical, 2 Coaxial
Analog Audio Inputs	6
Phono Input	Yes
Speaker Connectors	Binding Posts
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Surround Sound Support	Dolby Atmos, DTS:X, Auro-3D
Tuner	AM/FM
Input Sensitivity/Impedance	200 mV / 47 kohms
HDCP Support	2.2
Other Connections	USB, Ethernet, RS-232C
Wireless Connectivity	Wi-Fi, Bluetooth
Signal-to-Noise Ratio	102 dB
DAC	AKM AK4490EQ (32-bit/192kHz)
Total Harmonic Distortion	0.05% (20Hz - 20kHz, 150W)
