Denon AVR-X8500H Upgrade Information

6
Packing the product (US and Canada only)
Once you received an empty box, follow the instructions below to pack the product. It will help
prevent damages during shipment.
2 Preparation
① Remove the left and right antennas
on the rear panel.
Keep the antennas at home and attach
them again to the product once the product
is returned after the upgrade.
NOTE
• If the product is packed with the antennas
attached, the antennas will be damaged.
• Also keep other accessories such as the
remote control unit at home. They do not need
to be shipped with the product.
② To protect the door during shipment,
insert the provided door cushion into
the door as shown in the diagram,
close the door, and then fix the door
in place with tape.
To tape up the door, use the blue tape affixed
to the provided product packing sheet.
1.SPK610-611_RMF_ENG_00A_210408.indd 61.SPK610-611_RMF_ENG_00A_210408.indd 6 2021/04/08 11:19:262021/04/08 11:19:26
PrintingColor:Black

Denon AVR-X8500H Specifications

General

Channels	13.2
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Frequency Response	10Hz-100kHz (+1, -3dB)
HDMI Inputs	8 (1 front)
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
HEOS Multi-room	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Impedance	4-16 ohms
HDR Compatibility	HDR10, Dolby Vision, HLG
Audio Return Channel (ARC)	Yes
Digital Audio Inputs	2 Optical, 2 Coaxial
Analog Audio Inputs	6
Phono Input	Yes
Speaker Connectors	Binding Posts
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Surround Sound Support	Dolby Atmos, DTS:X, Auro-3D
Tuner	AM/FM
Input Sensitivity/Impedance	200 mV / 47 kohms
HDCP Support	2.2
Other Connections	USB, Ethernet, RS-232C
Wireless Connectivity	Wi-Fi, Bluetooth
Signal-to-Noise Ratio	102 dB
DAC	AKM AK4490EQ (32-bit/192kHz)
Total Harmonic Distortion	0.05% (20Hz - 20kHz, 150W)
