Denon AVR-X8500H Upgrade Information

5
Important post-upgrade notes
2Once the upgrade is performed, the following settings will reset to factory
default settings. The backup memory such as volume level will be erased
as well. It is necessary to setup the product once again when the product is
returned.
• Audyssey
®
Setup
• Speaker Config.
• Changing the “Quick Select Names”
• Network connection
• Last function memory
• Various settings using the custom installer
• All the other settings in the backup memory
NOTE
• The “Save & Load” function does not work. The saved settings can not be restored once the upgrade
is performed on the product.
2The warranty period of the product is the same as before the upgrade.
2 If the upgrade is performed, the product cannot be returned to the state before
the upgrade.
1.SPK610-611_RMF_ENG_00A_210408.indd 51.SPK610-611_RMF_ENG_00A_210408.indd 5 2021/04/08 11:19:262021/04/08 11:19:26
PrintingColor:Black

Denon AVR-X8500H Specifications

General

Channels	13.2
Power Output	150W per channel (8 ohms, 20Hz-20kHz, 0.05% THD)
Frequency Response	10Hz-100kHz (+1, -3dB)
HDMI Inputs	8 (1 front)
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
HEOS Multi-room	Yes
Wi-Fi	Yes
Bluetooth	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Impedance	4-16 ohms
HDR Compatibility	HDR10, Dolby Vision, HLG
Audio Return Channel (ARC)	Yes
Digital Audio Inputs	2 Optical, 2 Coaxial
Analog Audio Inputs	6
Phono Input	Yes
Speaker Connectors	Binding Posts
Supported Audio Formats	MP3, WMA, AAC, FLAC, ALAC, WAV, DSD
Surround Sound Support	Dolby Atmos, DTS:X, Auro-3D
Tuner	AM/FM
Input Sensitivity/Impedance	200 mV / 47 kohms
HDCP Support	2.2
Other Connections	USB, Ethernet, RS-232C
Wireless Connectivity	Wi-Fi, Bluetooth
Signal-to-Noise Ratio	102 dB
DAC	AKM AK4490EQ (32-bit/192kHz)
Total Harmonic Distortion	0.05% (20Hz - 20kHz, 150W)
