Denon CEOL RCD-N11DAB User Manual

0
When “TV Input” is set in the menu, this unit automatically turns on when the TV
connected to the unit is turned on, and the input source switches to “Optical In 1”
or “Optical In 2”. (v p. 90)
NOTE
0
Do not input non-PCM signals, such as Dolby Digital and DTS. This causes noise
and could damage the speakers.
o
Specifications of supported audio formats
See “DIGITAL IN” (v p. 134).
Playing analog input
1
Prepare for playback.
Check the connection, then turn on this units.
2
Press ANALOG IN to switch the input source to
“Analog In”.
3
Play the component connected to this unit.
Contents Connections Playback Settings Tips Appendix
68
Front/Top
panel
Rear panel
Remote control
unit
Index

Denon CEOL RCD-N11DAB Specifications

General

Type	Home audio micro system
Cassette deck	No
Product color	Black
Optical disc player	Yes
Apple docking	-
Headphone outputs	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Digital audio optical in	2
Channels quantity	2 channels
Disc types supported	CD, CD-R, CD-RW
Audio formats supported	AAC, ALAC, DSD, FLAC, MP3, WAV, WMA
Impedance	6 Ω
Speaker type	2-way
Frequency range	50 - 20000 Hz
RMS rated power	- W
Woofer diameter	120 mm
Tweeter diameter	30 mm
Signal-to-Noise Ratio (SNR)	74 dB
Total Harmonic Distortion (THD)	0.7 %
Volume control	Touch
Supported radio bands	AM, DAB, DAB+, FM
Internet radio services supported	Amazon Music, Deezer, Pandora, Spotify, Tidal, TuneIn
Power source	AC
Input voltage	230 V
Input frequency	50/60 Hz
Power consumption (standby)	0.4 W
Power consumption (typical)	55 W
Display type	OLED

Weight and Dimensions

Package type	Box
Package depth	390 mm
Package width	380 mm
Package height	513 mm
Package weight	6000 g
Main unit weight	3400 g
Main unit dimensions (WxDxH)	280 x 305 x 108 mm
