Denon D-E500 - Level Diagram

30
RCD-M37 / RCD-M37DAB / D-E500 / D-M37
LEVEL DIAGRAM
DAB UNIT
NJW1153 NJM2068 STK4142
FUNCTION
TUNER
SWITCH
MASTER TONE POWER AMP
PACK DAB VOLUME CONTROL
TUNER Buffer Buffer Buffer MUTE RELAY
CD UNIT Buffer CD/USB SP OUT
AK4385 DAC RELAY
USB HP OUT
Portable In LINE1䋨Dock䋩 IN
LINE2 IN
MUTE
LINE2 OUT PREOUT
SP OUT
+20dB 30W/6ohm
NJW1153 Max output,4Vrms(+12dB) 13.4V(22.5dB)
+10dB
8dB
0dB CD/USB 1KHz 0dB PB 1.0V SDB+8dB:1.59Vrms/+4dB (+28.6dB) HP OUT
DAB 1KHz 0dB 0.6V TONE+10dB:0.63Vrms/-4.0dB 1.0V/32ohm
-10dB
LINE IN 200mV '(+10dB)
-20dB FM 30%MOD 213mV -30dB -40dB
S/N:96dBtyp
-50dB -60dB
Output Noise Level -110dBv typ
