Denon DCD-F101 - Display P.W.B. Removal; Power P.W.B. Removal

DCD-F101
4
Power P.W.B.
Connector
7
6
4. Power P.W.B.
1) Remove 2 screws
6
and 1 screw
7
.
2) Lift the Power P.W.B., and disconnect a connector
(connected with the µ-com P.W.B.).
3) Disconnect a connector (connected with the trans).
µ-com P.W.B.
5
Display P.W.B.
3. Display P.W.B.
1) Remove 8 screws
5
and detach the Display P.W.B.
5
