Denon DN S5000 - DJ Table Top Single CD Player Service Manual

15
15DN-S5000
Function
Pin
No.
Port Name
Symbol
(IC301)
I/O DET Ext Ini
Symbol
(IC401)
Res
95VDD VDD VDD —————Power (+3.3V)
96DATA9 I/O————Ext. bus data 9
97DATA10 I/O————Ext. bus data 10
98DATA11 I/O————Ext. bus data 11
99GND GND GND —————GND
100DATA12 I/O————Ext. bus data 12
101DATA13 I/O————Ext. bus data 13
102NC —————NC
103NC —————NC
104DATA14 I/O————Ext. bus data 14
105VDD VDD VDD —————Power (+3.3V)
106GND GND GND —————GND
107DATA15 I/O————Ext. bus data 15
108DATA16 I/O————Ext. bus data 16
109DATA17 I/O————Ext. bus data 17
110VDD VDD VDD —————Power (+3.3V)
111DATA18 I/O————Ext. bus data 18
112DATA19 I/O————Ext. bus data 19
113DATA20 I/O————Ext. bus data 20
114GND GND GND —————GND
115NC —————NC
116DATA21 I/O————Ext. bus data 21
117DATA22 I/O————Ext. bus data 22
118DATA23 I/O————Ext. bus data 23
119GND GND GND —————GND
120VDD VDD VDD —————Power (+3.3V)
121DATA24 I/O————Ext. bus data 24
122DATA25 I/O————Ext. bus data 25
123DATA26 I/O————Ext. bus data 26
124VDD VDD VDD —————Power (+3.3V)
125GND GND GND —————GND
126DATA27 I/O————Ext. bus data 27
127DATA28 I/O————Ext. bus data 28
128DATA29 I/O————Ext. bus data 29
129GND GND GND —————GND
130VDD VDD VDD —————Power (+3.3V)
131VDD VDD VDD —————Power (+3.3V)
132DATA30 I/O————Ext. bus data 30
133DATA31 I/O————Ext. bus data 31
134 FLAG7 DFLG12 DFLG22 I/O — Pu — H General flag 7 (RESERVE)
135GND GND GND —————GND
136 FLAG6 DFLG11 DFLG21 I/O — Pu — H General flag 6 (RESERVE)
137 FLAG5 DTIMB1 DTIMB2 O — — — — General flag 5 (Pulse output for generating monitor play time)
138 FLAG4 DTIMA1 DTIMA2 O — — — — General flag 4 (Pulse output for generating main play time)
139GND GND GND —————GND
140VDD VDD VDD —————Power (+3.3V)
141VDD VDD VDD —————Power (+3.3V)
142NC —————NC
143 ID1 I — — L L Multi-processing ID1 (Single processor: 0)
144 ID0 I — — L L Multi-processing ID2 (Single processor: 0)
145 EMU_ EMU1_ EMU2_ O — — — — Emulation status
146
TD0 TD01 TD02 O — — — — Test data output (JTAG)
147 TRST_ TRST1_ TRST2_ I — IPu — H Test reset (JTAG)
148 TDI TDI1 TDI2 I — Pd — L Test data input (JTAG)
149 TMS TMS1 TMS2 I — IPu — H Test mode select (JTAG)
150GND GND GND —————GND
151 TCK TCK1 TCK2 I — Pu — H Test clock (JTAG)
152 BSEL I — — H H EPROM boot select (Boot by EPROM: 1)
153 BMS_ BMS1_ BMS2_ I — — H H Boot memory select (Host processor boot: 1)
154GND GND GND —————GND
155GND GND GND —————GND
156VDD VDD VDD —————Power (+3.3V)
