Denon DN S5000 - DJ Table Top Single CD Player Service Manual

16
16DN-S5000
157 RESET_ DRES_ DRES_ I — — H L DSP reset signal
158VDD VDD VDD —————Power (+3.3V)
159GND GND GND —————GND
160 ADDR23 I/O ————Ext. bus address 23
161 ADDR22 I/O ————Ext. bus address 22
162 ADDR21 I/O ————Ext. bus address 21
163VDD VDD VDD —————Power (+3.3V)
164 ADDR20 I/O ————Ext. bus address 20
165 ADDR19 I/O ————Ext. bus address 19
166 ADDR18 I/O ————Ext. bus address 18
167GND GND GND —————GND
168GND GND GND —————GND
169 ADDR17 I/O ————Ext. bus address 17
170 ADDR16 I/O ————Ext. bus address 16
171 ADDR15 I/O ————Ext. bus address 15
172VDD VDD VDD —————Power (+3.3V)
173 ADDR14 I/O ————Ext. bus address 14
174 ADDR13 I/O ————Ext. bus address 13
175 ADDR12 I/O ————Ext. bus address 12
176VDD VDD VDD —————Power (+3.3V)
177GND GND GND —————GND
178 ADDR11 I/O ————Ext. bus address 11
179 ADDR10 I/O ————Ext. bus address 10 (SDRAM: Connects SDA10)
180 ADDR9 I/O ————Ext. bus address 9
181GND GND GND —————GND
182VDD VDD VDD —————Power (+3.3V)
183 ADDR8 I/O ————Ext. bus address 8
184 ADDR7 I/O ————Ext. bus address 7
185 ADDR6 I/O ————Ext. bus address 6
186GND GND GND —————GND
187GND GND GND —————GND
188 ADDR5 I/O ————Ext. bus address 5
189 ADDR4 I/O ————Ext. bus address 4
190 ADDR3 I/O ————Ext. bus address 3
191VDD VDD VDD —————Power (+3.3V)
192VDD VDD VDD —————Power (+3.3V)
193 ADDR2 I/O ————Ext. bus address 2
194 ADDR1 I/O ————Ext. bus address 1
195 ADDR0 I/O ————Ext. bus address 0
196GND GND GND —————GND
197 FLAG0 DR_/W1 DR_/W2 I/O ————General flag 0 (Command read write select)
198 FLAG1 DACK1_ DACK2_ I/O ————General flag 1
199 FLAG2 DBSY1 DBSY2 I/O ————General flag 2
200VDD VDD VDD —————Power (+3.3V)
201 FLAG3 DFLG10 DFLG20 I/O — Pu — H General flag 3 (RESERVE)
202NC ——————
203NC ——————
204GND GND GND —————GND
205 IRQ0_ DREQ1 DREQ2 I — Pu — H Interrupt request input 0 (SYS mcom interface)
206 IRQ1_ DREQ1_ DREQ2_ I — Pu — L Interrupt request input 1 (SYS mcom interface)
207 IRQ2_ JOGINT1 JOGINT2 I — — — — Interrupt request input 2 (JOG turning speed detect signal)
208
NC —————NC
Function
Pin
No.
Port Name
Symbol
(IC301)
I/O DET Ext Ini
Symbol
(IC401)
Res
