6
Turn the anti-skating dial so
that it is lined up with “2”.
Turn twist the counterweight so that the tone
arm is oating parallel to the turntable.
•
Perform adjustment by turning the counterweight
gradually while periodically removing your hand to
check the position.
Parallel
Return the tone arm to the armrest.
Holding the counterweight with a nger so
that it does not move, turn the stylus pressure
adjustment ring so that its “0” mark is lined
up with the line on the tone arm.
Stylus pressure
adjustment ring
5
4
6
n Adjusting anti-skating
1
Turn the counterweight in the direction of
the arrow so that the “2” mark of the stylus
pressure adjustment ring is lined up with the
single line on the tone arm.
• The appropriate stylus pressure for the cartridge included with
the main unit is 2.0 g (19.6 mN).
7
