After having confirmed that the setting is correct, the mir-
ror tape may warp anyway. In order to establish the titit
angles of the recording/plaback head and the erase head,
adjust (by turning 1/4 — 1/2 turns) the level adjusting screw
(311) of the tape guide (103). Refer to the pages on
“Adjusting and checking the Mechanism Section’’ when
replacing or adjusting the R/P HEAD.
2.
Adjusting
the
Azimuth
(1)
After
completing
the
tape
transport
check
load
the
test
tape
(TEAC
MTT-114).
(2) Play back the test tape; adjust the azimuth nut so
that section A of the resurge wave form is maximum
and section B is minimum.
3. Checking and Adjusting the Tape Speed
1) Connect the frequency counter to the LINE OUT
terminal and load the test tape (TEAC MTT-111).
2) Playback a test tape. At about halfway through the
tape, where the tape transport is stable, adjust the
adjustment points on the back of the capstan motor
so that the frequency counter will have a reading with-
in the the range of 3,000 Hz + 6Hz.
F Counter
LINE OUT
3000 Hz
T6Hz
MTT-H1
Playback
Frequency
Response
4. Adjusting the Input Sensitivity
(1) Set the MONITOR switch to SOURCE position, the
operational mode at STOP. Supply a 400 Hz signal
to the LINE IN terminal and set the input signal level
(approx. —20 dB) so that the output level at the LINE
OUT TERMINAL (L ch) becaomes OdB.
DC motor
Hole sensor P.W.B
Capstan motor
(2) At the same time, check to make sure the R ch output
level is also OdB.
REC Amp
LINE IN
“TSO
LINE OUT
5. Adjusting Playback Section
(1) Adjusting the playback level
Play back the Dolby standard level test tape (TEAC
MTT-150)
and
adjust
RT
101
(L
ch),
RT
201
(R
ch)
so that the LINE OUT voltage becomes 0 dB (0.775V).
(2) Adjusting the playback frequency response
Play back the test tape (A-BEX TCC-262) and check
to make sure that the frequency response meets the
specifications in the diagram.
PB Amp
LINE OUT
J
Tape: A-BEX TCC-262
When using MTT-316 make corrections along.
aes as CR A He 0
aoe eR Ha SE DA
er OS ee ae
10k 20k (Hz)
