I
Ref. No.
Part No.Part NameRemarks
9
3910267008REC/P.B HEAD
10
4438671104
SPECIAL NUT
11
445 8028009
CORD HOLDER
20
4330540003HOOK STOPPER
21
4610154083CUSHION
23
4338194105PINCH ROLLER ARM
ASS'Y
24
4638231 108SPRING
25
4210446104REEL DRIVER
26
463 0522 103SPRING
27
463 0538 003SPRING
28
4218401 109REEL DRIVE WHEEL
29
4330449201
IDLER ARM (B)GEAR
ASS'Y
30
4410692101LAMP HOLDER
35
433 8236 306
IDLER ARM (A) ASS'Y
36
4638271 003SPRING
37
2170161000REEL MOTOR
38
421 8403 000PULLEY
39
441 0850008
DC MOTOR FIX
PLATE40
431 0241 005BRAKE
41
4618127106BRAKE SHOE
42
463 8234 105SPRING
43
433 8232 300BRAKE ARM ASS'Y
44
443 8648 302METAL HOUSING
ASS'Y
45
4210389106FLYWHEEL ASS'Y
47
441 1069607
MECHA STAY ASS'Y
50
477 0090074WASHER
52
411 8966402CAM MOTOR
HOLDER53
2170168003
CAM MOTOR
54
4248025 607WORM GEAR
55
4240142009
CAM
56
4140414206
OIL FENCE
57
4428018308ENCODER BRACKET
58
433 0493 105
HOLE SENSOR (A)
59
433 0494 104
HOLE SENSOR (B)
60
433 0495 103
HOLE SENSOR (C)
67
GEN0410CASSETTE BOX SUB
ASS'Y
68
1031209400CASSETTE BOX
69
433 0459 411C. BOX HOLDER
72
431 8097002COLLAR
73
4630524101BOX SPRING
74
4698013133AIR DUMPER
76
1441859107ESC. PLATE
77
3939179012
LNO105YP4(YW)
78
445 8028 009CORD HOLDER
79
4U-1831-42HOLE SENSOR PWB
ASS'Y
80
2123331 308ROTARY ENCODER
81
3939178000LN25RCP
82
3939026013PN150C
83
2124665002
SLIDE SWITCH
84
4U- 1831- 43REEL PULSE PWB
ASS'Y
90
103 1221 514STABILIZER
91
4630609 107STABILIZER SPRING
92
4610491 209
STABILIZER PAD (A)
Ref. No.
Part No.Part NameRemarks
93
461 0488 005
STABILIZER PAD (B)
100
443 0903 207HEAD BLOCK
103
433 0407 308TAPE GUIDE
104
433 0408 006PINCH ROLLER ARM
(L) ASS'Y
105
4630414101SPRING
106
463 0480 009SPRING
107
4430539008WASHER
108
477 0240002WASHER
111
4210538106CAPSTAN WHEEL
ASS'Y
112
423 8026 108BELT
113
4238030110BELT
150
4630616006SPRING
152
2170162009
CAPSTAN MOTOR
153
421 8383 007
MOTOR PULLEY
154
4630618004
FLYWHEEL SPRING
155
425 8058004WASHER
158
4U- 1831 -4MECHA. PWB UNIT
159
DRO4A04
REEL MOTOR SUB
ASS'Y
160
DCO 7A02CAPSTAN MOTOR
SUB ASS'Y161
DCO 6A03CAM MOTOR SUB
ASS'Y
171
471 1822010CAMERA SCREW
2 x8
180
463 0628 104DUMPER SPRING
181
47510030063W
182
461 0473201THRUST STOPPER
183
443 0948 000
SHIELD COVER
200
463 8829 303
CASSETTE SPRING
201
4428154107CP SUPPORT
202
4410897003SPRING GUIDE
203
433 0543 204HOOK
204
463 0561 009SPRING
205
412 8829 305ANGLE
206
4638257001SPRING
208
1038243401CASSETTE SUPPORT
(L)
209
103 8243 414CASSETTE SUPPORT
(R)
210
4338271 507DUMPER GUIDE
301
473 7002 005
3 x6 CBTS(S)-Z
307
47132020102.6 x5 CBS
308
4737021002
2.6 x6 CFT(S)
310
471 38020252.6 x 14 CBS
311
4756020000
2NUT
312
47138020122.6 x3 CBS-Z
313
4737001006
2.6 x5 CBTS(S)-Z
314
4770265016WASHER
315
477 0269 009
NYLON NUT (M2)
316
4620086015MOTOR CUSHION
317
4751121 108
SLIT WASHER
318
4737500002
3 x6 CBTS(P)-Z
319
47611140081.5 E.RING
320
4713801039
2 x3 CBS-Z
321
4751120109
SLIT WASHER
322
477 0294003
SPECIAL SCREW
323
47610030093 E.RING
329
4751139103
2.1 WASHER
j /
