DVD-2900
(4) SACD check process
O.K.
N.G.
Check soldering
• [IC404]
• R437--R449.
Check RF signal for Water Mark.
• TP [WM]: about 1V
p-p.
Check soldering
• [IC401]: 141--162pin.
• [IC402]
END
N.G.
Check Bus Line.
Between IC401 and IC402(16MSDRAM)
“L”-”H” level alternate?
Check communication.
• [VSTEM]: communication
“L”--”H” level alternate?
Check soldering
• [IC403]: Circumference soldering check
N.G.
O.K.
