Denon DVD-2930 Service Manual

67
DVD-2930/2930CI
2. TRANSISTORS
RSS100N03TB (PD: TR910) HN1K02FU (DI: TR803)
3. DIODE
RL10Z (PD: D913)
4. LED
SML1216W (PD: LD103)
5. OTHERS
GP1UE271XKVF (Remote Control Sensor) (PD: IC102)
(8) (7) (6) (5)
(1) (2) (3) (4)
(1)
(1) Source
(2) Source
(3) Source
(4) Gate
(5) Drain
(6) Drain
(7) Drain
(8) Drain
(2) (3) (4)
(8) (7) (6) (5)
21
Q1
Q2
3
654
1. Source 1
2. Gate 1
3. Drain 2
4. Source 2
5. Gate 2
6. Drain 1
RED GREEN
1
1
2
3
23
GND
V CC
V
OUT
B.P.F
Integrator
VOUT
VCC
GND
Limiter Demodulator Comparator
RL
