RCD-M35DAB/M33
85 P01 O Not Used: N. C. L
86 P00 O Not Used: N. C. L
87 P107 I Pull up HI-Z
88 P106 I USA Initial Setting input HI-Z
89 P105 I EURO Initial Setting input HI-Z
90 P104 O P.ON/OFF Main POWER ON/STANDBY switching output. ON: High L
91 AN3 I FREQ Initial Setting input HI-Z
92 AN2 I RDS Initial Setting input HI-Z
93 AN1 I KEY 0 Unit Operation Button input 1 HI-Z
94 AVSS (VSS) GND -
95 AN0 I KEY 1 Unit Operation Button input 1 -
96 VREF (VCC) Positive power -
97 AVCC (VCC) Positive power -
98 P96 SI /DBRXD (DENON BUS) Serial Data input for DENON BUS HI-Z
99 P97 SO /DBTXD (DENON BUS) Serial Data output for DENON BUS H
100 P95 SO /DBCLK (DENON BUS) Serial Clock output for DENON BUS H
