RCD-M35DAB/M33
30 P66 SI FLASH RxD DATA BUS (Flash rom write) DATA input HI-Z
31 CLK1 I Pull down L
32 P64 O Not Used: N. C. L
33 TXD0 SI S1_DIN Serial Data input from DAB Module L
34 RXD0 SO S1_DOUT Serial Data output to DAB Module L
35 CLK0 O Not Used: N. C. L
36 P60 O PWRON (CD) CD MPU Power ON/OFF Switching output L
37 P57 O /CD RESET Reset output to CD MPU L
38 P56 I H/P SW HEAD PHONE insert detect signal input HI-Z
39 P55 O LED G POWER/STANDBY Green LED output, ON:High L
40 P54 SO E2P CLK Serial Clock output to EEPROM L
41 P53 SI E2P DO Serial Data input from EEPROM HI-Z
42 P52 SO E2P DI Serial Data output to EEPROM L
43 P51 O E2P CS Chip Enable output to EEPROM L
44 P50 O LED R POWER/STANDBY Red LED output, ON:High H
45 P47 O E2P CS1 Chip Enable output to EEPROM(patch) L
46 P46 I Pull down HI-Z
47 P45 I Pull down HI-Z
48 P44 I Pull down HI-Z
49 P43 I Pull down HI-Z
50 P42 O Not Used: N. C. L
51 P41 O CDPWR CD circuit Power ON/OFF Switching output. ON: High L
52 P40 O /DABMUTE MUTE output to DAB Module. MUTE: Low L
53 P37 O /FMAM TUNER Select to DAB or FM/AM. DAB: High, FM/AM: Low L
54 P36 O Not Used: N. C. L
55 P35 O VR MUTE MUTE output to POWER AMP IC input. MUTE: Low L
56 P34 O RL SPEAKER RELAY ON/OFF output. ONÅFHigh L
57 P33 O SW MUTE MUTE output toPRE OUT. MUTE: Low L
58 P32 O L1 LINE OUT control output 1 L
59 P31 O L2 LINE OUT control output 2 L
60 VCC (VCC) GND -
61 P30 O H/P MUTE MUTE output to HEAD PHONE output. MUTE: Low HEAD
PHONE MUTE output. L: MUTE-ON
L
62 VSS (VSS) GND -
63 P27 O Not Used: N. C. L
64 P26 I STEREO "STEREO" indicator input from FM/AM TUNER pack HI-Z
65 P25 I TUNED "TUNED" detect input from FM/AM TUNER pack HI-Z
66 P24 O T.MUTE MUTE output to FM/AM TUNER pack. MUTE: Low L
67 P23 O SANYO CE Chip Enable output to PLL/RDS/VR IC L
68 P22 O SANYO DI Serial Data output to PLL/RDS/VR IC L
69 P21 O SANYO CLK Serial Clock output to PLL/RDS/VR IC L
70 P20 I SANYO DO Serial Data input from PLL/RDS/VR IC HI-Z
71 P17 O Not Used: N. C. L
72 P16 O Not Used: N. C. L
73 INT3 INT REMOTE Remote Control signal input HI-Z
74 P14 O /SYR Reset output to RDS IC L
75 P13 O D.OUT MUTE MUTE ouput for Digital signal (OPT) output. MUTE: High HI-Z
76 P12 I CLSW CD LOADER CLOSE SW input HI-Z
77 P11 I OPSW CD LOADER OPEN SW input HI-Z
78 P10 O Not Used: N. C. HI-Z
79 P07 O OPEN CD LOADING MOTOR OPEN output L
80 P06 O CLOSE CD LOADING MOTER CLOSE output L
81 P05 O Not Used: N. C. L
82 P04 O Not Used: N. C. L
83 P03 O Not Used: N. C. L
84 P02 O Not Used: N. C. L
