S-102
HD8
132
I/O Host data bus line; (5V tolerant input).
DCI_FDS# I/O DVD input sector start; (5V tolerant input).
AUX2[0] I/O Aux2 data I/O; (5V tolerant input).
VFD_CLK I VFD clock input.
HD9
133
I/O Host data bus line; (5V tolerant input).
AUX2[1] I/O Aux2 data I/O; (5V tolerant input).
HD10
134
I/O Host data bus line; (5V tolerant input).
AUX2[2] I/O Aux2 data I/O; (5V tolerant input).
HD11
135
I/O Host data bus line; (5V tolerant input).
AUX2[3] I/O Aux2 data I/O; (5V tolerant input).
IRQ O IRQ.
HD12
136
I/O Host data bus line; (5V tolerant input).
AUX2[4] I/O Aux2 data I/O; (5V tolerant input).
C2PO I C2PO error correction flag from CD-ROM; (5V tolerant input).
HD13
137
I/O Host data bus line; (5V tolerant input).
AUX2[5] I/O Aux2 data I/O; (5V tolerant input).
SP I 16550 UART serial port input.
HD14
140
I/O Host data bus line; (5V tolerant input).
AUX2[6] I/O Aux2 data I/O; (5V tolerant input).
HD15
141
I/O Host data bus line; (5V tolerant input).
AUX2[7] I/O Aux2 data I/O; (5V tolerant input).
IR I IR remote control input; (5V tolerant input).
HWRQ#
142
O Host write request.
DCI_REQ# O DVD control interface request.
AUX4[1] I/O Aux4 data I/O; (5V tolerant input).
HRRQ#
143
O Host read request.
AUX4[0] I/O Aux4 data I/O; (5V tolerant input).
CAMIN2 I Camera YUV 2.
PIXIN2 I CCIR656 input pixel 2.
HIRQ
144
I/O Host interrupt.
DCI_ERR# I/O DVD channel data error; (5V tolerant input).
AUX4[7] I/O Aux4 data I/O; (5V tolerant input).
HRST#
145
OHost reset.
AUX3[5] I/O Aux3 data I/O; (5V tolerant input).
HIORDY
146
I Host I/O ready.
AUX3[3] I/O Aux3 data I/O; (5V tolerant input).
