Denon S-102 - Page 55

55
S-102
[ ]:Reserved
81 P123 O SAN_MOSI Serial Data output to TUNER/RDS IC
82 P122 O /CODEC_RST Reset output to CODEC
83 P121 O PRE_MUTE_SUB MUTE output to PRE OUT. H:MUTE
84 P120 O HP_MUTE_SUB MUTE output to HEAD PHONE output. H:MUTE
85 VCC2 - VCC2 Positive power
86 P30 O BE/_DIR Select audio line output.(H:ESS,L:DIR)
87 VSS - VSS GND
88 P27 O CODEC_CE Chip Enable output to CODEC
89 P26 O NC(L:Output) Not Used:N.C.
90 P25 O DSP_IO_MUTE DSP IO MUTE output(H:Mute)
91 P24 O /AD/DIG Select audio line output.(H:DIGITAL, L:ADC IN)
92 P23 O /ERR_MUTE MUTE output at DSP Error.
93 P22 O /BSE Bit Stream Enable output(L:Enable)
94 P21 O NC(L:Output) Not Used:N.C.
95 P20 O NC(L:Output) Not Used:N.C.
96 INT5 INT /PROTECT Protect Signal input.
97 P16 O NC(L:Output) Not Used:N.C.
98 INT3 INT /REMOCON Remote Control signal input
99 P14 O NC(L:Output) Not Used:N.C.
100 P13 O PRE_MUTE_MAIN MUTE output to Output(H:Mute).
101 P12 O /COMP_MUTE COMPONENT VIDEO Mute output(H:Mute)
102 P11 O /S/V_MUTE S/COMPOSITE VIDEO Mute output(H:Mute)
103 P10 O /BE RST Reset output to ESS
104 P07 O DRV_ON DRIVE POWER ON output(H:P.ON)
105 P06 O SYS_REQ SYSTEM REQEST output to ESS.
106 P05 I BE ON Active Flag input from ESS.
107 P04 O NC(L:Output) Not Used:N.C.
108 P03 O NC(L:Output) Not Used:N.C.
109 P02 O /DIR_RST Reset output to DIR.
110 P01 O DIR_CE Chip Enable output to DIR
111 P00 O DIR/CODEC_CK Serial Clock output to DIR/CODEC.
112 P117 I DIR_MISO Serial Data input from DIR.
113 P116 O DIR/CODEC_MOSI Serial Data output to DIR/CODEC
114 P115 O /DSPROM_RST Reset output to DSP ROM.
115 P114 O /DSP_RST Reset output to DSP.
116 P113 O DSP_CS Chip Select output to DSP
117 P112 I FLAG0 DSP FLAG0 input
118 P111 O FAN_ON FAN ON/OFF output.H:FAN ON
119 P110 O FAN SPEED FAN SPEED Control output(H:Slow L:Fast)
120 P107/AN7 I Pull uÇê Pull up
121 P106/AN6 AD KEY2 Unit Operation Button input2
122 P105/AN5 AD KEY1 Unit Operation Button input1
123 P104/AN4 AD KEY0 Unit Operation Button input0
124 P103/AN3 AD MODE2_S102 Initial Setting input for Region No of DVD.
125 P102/AN2 AD MODE1_S102 Initial Setting input the destination.(E2,E3)
126 P101/AN1 O Pull up Pull up
127 AVSS - AVSS GND
128 SW1_IN AD SW1_IN Select signal input of Video Signal. (H:HDMI/M:PROGRE/L:INTERLACE)
Pin
No
Port
Function
Port
setting
Port Name Explanation
