54
S-102
26 P81 EC P_DOWN( 50/60Hz ) 50Hz/60Hz AC input
27 P80 I PWB_CHK Checking PWB input
28 P77 O /SMONI_SELB SelecteYC Video outputB
29 P76 O /SMONI_SELA Selecte YC Video outputA
30 P75 I VOL_B VOL encoder Pulse-B input
31 P74 I VOL_A VOL encoder Pulse-A input
32 P73/CTS2 O NC(L:Output) Not Used:N.C.
33 P72/CLK2 I /TEMP_DET Temperature Detect signal input from posister
34 P71/RXD2 I IPOD_D_MRXD Serial Data input from IPOD
35 P70/TXD2 O IPOD_D_MTXD Serial Data output to IPOD
36 P67/TXD1 O F_TXD2 Serial Data out to Flash Memory.
37 VCC1 - VCC1 Positive power
38 P66 O F_RXD2 Serial Data input from Flash Memory.
39 VSS - VSS GND
40 P65 O LED_ORG Orenge(Yellow)LED output. L:ON
41 P64 O DC/DC_ON Power ON/OFF output to DC/DC Converter. H: Power ON
42 TXD0 SO BE_STXD Serial Data output to ESS
43 RXD0 SI BE_SRXD Serial Data input from ESS
44 CLK0 SI BE_CLK Serial Clock input from ESS
45 P60/CTS0 O NC(L:Output) Not Used:N.C.
46 P137 O NC(L:Output) Not Used:N.C.
47 P136 O HD/_SD Select signal output of Video Encoder Clock ( L:SD, H:HD)
48 P135 O /CHOP_ON CHOPER REG. ON/OFF output. L:ON
49 P134 O HDMI_DEBG6 For HDMI Debug
50 P57 O /ENC_RST Video Encoder Reset output
51 P56 O NC(L:Output) Not Used:N.C.
52 P55/EPM O F_EPM2 Writing Port for Flash Memory.
53 P54 I AUX_SW Front AUX IN insert detect signal input. H: Detected
54 P133 I HP_SW HEAD PHONE insert detect signal input. H: Detected
55 P132 O NC(L:Output) Not Used:N.C.
56 P131 O HDMI_OE HDMI Output Enable(Active Low)
57 P130 O /VPLD_RST Reset output to VPLD.
58 P53 O NC(L:Output) Not Used:N.C.
59 P52 O LED_RED Red LED output. L:ON
60 P51 O LED_BLU Blue LED output. H:ON
61 P50/CE O /F_CE2 Chip Enable output to Flash Memory.
62 P127 O NC(L:Output) Not Used:N.C.
63 P126 O E2P_CS Chip Select output to EEPROM
64 P125 O SAN_CE Chip Enable output to TUNER/RDS IC
65 P47 O E2P_CLK Serial Clock output to EEPROM
66 P46 O E2P_MOSI Serial Data output to EEPROM
67 P45 O FNVL_DA Serial Data output to FUNC/VOL IC.
68 P44 O FNVL_CK Serial Clock output to FUNC/VOL IC.
69 P43 O FNVL_CE Chip Enable output to FUNC/VOL IC.
70 P42 I E2P_MISO Serial Data input to EEPROM
71 P41 I SAN_MISO Serial Data input from TUNER/RDS IC
72 P40 I TU_STEREO "STEREO" indicator input from FM/AM TUNER pack
73 P37 I TUNED "TUNED" detect input from FM/AM TUNER pack
74 P36 O /TU_MU MUTE output to TUNER. L:MUTE
75 P35 O TU_POWER TUNER Power ON/OFF output. H: Power ON
76 P34 O /SAN_RST Reset output to TUNER/RDS IC
77 P33 O SP_RL SP RELAY ON/OFF output. H:ON
78 P32 I CODEC_MISO Serial Data input from CODEC
79 P31 O NC(L:Output) Not Used:N.C.
80 P124 O SAN_CK Serial Clock output to TUNER/RDS IC
Pin
No
Port
Function
Port
setting
Port Name Explanation
