4 Product Specifications
- 11 -
4 Product Specifications
*1 For models with Bluetooth only
*2 Some functions require the support software.
*3 This product can be turned on by the power supplied from the USB power (BUS power). However, vehicle
communication cannot be established when the power is not supplied from the vehicle.
4-1 Specifications of This Product
Item Specifications
OS
µiTRON
CPU 32-bit RISC microcomputer
Memory
Built-in Flash ROM 16 MB
SDRAM 16 MB
EEPROM 32 KB
LCD
Size 2.7 inch TFT color LCD
Resolution QVGA (320 x 240 dots)
Display color Max. 260000 colors
Input device Operation keys 6 keys
External interface
*2
USB USB 2.0 x 1
Bluetooth
*1
Bluetooth 2.0
SD memory card Slot x 1 (supporting SD and SDHC memory cards)
DC jack JEITA4 standard type
Vehicle communication
Dedicated connector (D-sub 25 pin) x 1
ISO9141, CAN
Main unit power
supply voltage
Vehicle power supply DC 6.5 to 32 V (Datalink cable)
USB power (BUS power)
DC 4.75 to 5.25 V
*3
Power consumption Normally 1.5 W (12 VDC), Max. 2.5 W (12 VDC)
Operating
environment
Operating temperature
[Storage temperature]
0 to 50°C [-10 to 60°C]
Operating humidity 35 to 85% (No condensation)
Dimensions 135 mm (W) x 70 mm (H) x 35 mm (D)
Weight
Model without Bluetooth Approx. 225 g
Model with Bluetooth Approx. 230 g
