PARTS


This list contains replaceable parts used in your replace. When ordering parts, follow the
instructions listed under Replacement Parts on page 37 of this manual.

  DESCRIPTION 
1 11102 Screw #8-32 x 3/8 PPH Zinc 2
2 11105 Screw #10 x 1/2 Zinc 9
3 11179 Screw #10-24 x 1/4 Zinc 4
4 11237 Screw, Trilab M4 x 8 mm 1
5 14389 Millivolt Valve (Natural Gas) 1
14390 Millivolt Valve (Propane/LP Gas) 1
117370-01 Millivolt Valve (NG-High Altitude) 1
6 14492 Piezo Ignitor 1
7 14500 Brass Fitting 2
8 14253 Flexible Connector 1
9 14511 Ignitor Bracket 1
10 14528 Brass Elbow Fitting 1
11 104506-25 Orice (Natural #47) 1
104506-02 Orice (Propane/LP #55) 1
12 104509-02 Aluminum Tubing Assembly 1
13 26808 Valve Bracket 1
14 26827 Switch Bracket 1
15 108886-01 Base Grate Assembly 1
16 108891-01 Burner 1
17 108084-02 Pilot Assembly (Natural) 1
108084-03 Pilot Assembly (Propane/LP) 1
108084-05 Pilot Assembly (NG-High Altitude) 1
18 ** Burner Base Assembly 1
19 27113 Air Deector 1
** Not a eld replaceable part.
