7.3.2. SHIFTING MOTORIZED CYLINDER TO ENROLLING NEW CONTROLLER MODE
- Wake the keypad up by putting your palm to the touch keys and then touch “M” button. “A” appears on the display.
- Enter 5 digit master password. After display animation, touch “6” button.
- The motorized cylinder will shift to enrolling new controller mode with a long and a short warning tone. Schematic
representation of operation is as follows:
DESi
12345
6
For auto-locking module;
take the magnet closer to
triangle sign and wait
indicator is lit.
For remote controller;
press and hold any
button.
For home automation interface;
power up the device and short-circuit and then open-circuit yellow and black cables.
3-12 V
DC
For other controllers,
send locking or unlocking
signal via related
controller.
For enrolling a new
mobile phone, please
check next page.
For fingerprint reader;
wake it up and touch the
locking button.
DESi
Just after the short warning tone;
