8.1.2. DELETE ALL ENROLLED CONTROLLERS
- Press 3rd button till “0" flashes on the display.
- Press 2nd button three times. “7" will be flashing on the display. Press 3rd button. “d” will be shown.
- Press 1st button. The motorized cylinder will give a long (10 sec) and two short warning tone
In this way, all the controllers (except the master rc) will be deleted from the device.
Schematic representation of operation is as follows:
61
1
2
3
3s 3X 10s Bp Bp Bp
