Desoutter EAD - Page 25

6159932570_09
25 / 10404/2014
EAD 20-1300 EAD 32-900 EAD 50-900 EAD 50-900-HAD EAD 70-700-HAD EAD 70-800 EAD 70-800 Sq.1/2 EAD 80-650 EAD 105-500 EAD 105-500-HAD EID 25-1200 EID 32-900 EID 44-1200 EID 65-900 EID 75-800
High Medium Low
Item Description Part no. Qty Qty Wear
J Output AHE4 6153972695 1 1 X
Needle bearing BK1012 - 1 1
Housing plug AHE4 - 1 1
Spacer - 1 1
Angle head housing
AHE4
- 1 1
Nut - 1 1
O-ring 17.1X1.6 - 1 1
J1 Bevel gear kit AHE4 6153973860 1 1 X
Driving pinion AHE4 - 1 1
Output wheel AHE4 - 1 1
J3 Socket retention kit 6153976640 1 1 X
Pin - 1 1
Spring pin 1,5 X 8 - 1 1
Spring Ø3.2 Lg 8 - 1 1
J4 Bearing kit AHE4 6153976710 1 1 X
Needle bearing BK1012 - 1 1
Needle bearing HK2016 - 1 1
Ball bearing 15x35x16 - 1 1
Housing plug - 1 1
Ball - 15 15
Kit output AHE4
J
J1
J3
J4
