Desoutter EAD - Page 26

6159932570_09
26 / 104 04/2014
EAD 20-1300 EAD 32-900 EAD 50-900 EAD 50-900-HAD EAD 70-700-HAD EAD 70-800 EAD 70-800 Sq.1/2 EAD 80-650 EAD 105-500 EAD 105-500-HAD EID 25-1200 EID 32-900 EID 44-1200 EID 65-900 EID 75-800
High Medium Low
Item Description Part no. Qty Qty Wear
J Output AHE2 HAD 6153982475 1 X
J1 Bevel gear set 6153982850 1 X
Bevel pinion HAD AHE2 - 1
Bevel gear 50 Nm - 1
J2 Service kit 6153982860 1 X
Bearing - 1
Bearing - 1
Needle bearing - 1
Circlip - 1
Ball - 20
O-ring - 1
Spring - 1
J3 Small parts kit 6153982870 1 X
Spacer - 1
Nut - 1
Parallel key - 1
Washer - 1
Kit output AHE2 HAD
J
J3
J3
J1
J2
