Desoutter EAD - Page 27

6159932570_09
27 / 10404/2014
EAD 20-1300 EAD 32-900 EAD 50-900 EAD 50-900-HAD EAD 70-700-HAD EAD 70-800 EAD 70-800 Sq.1/2 EAD 80-650 EAD 105-500 EAD 105-500-HAD EID 25-1200 EID 32-900 EID 44-1200 EID 65-900 EID 75-800
High Medium Low
Item Description Part no. Qty Qty Wear
J Output AHE3 HAD 6153982485 1 X
J1 Bevel gear set 6153982880 1 X
Bevel pinion HAD AHE3 - 1
Bevel gear 180 Nm - 1
J2 Service kit 6153982890 1 X
Bearing - 1
Bearing - 1
Needle bearing - 1
Circlip - 1
Ball - 20
O-ring - 1
Spring - 1
J3 Small parts kit 6153982900 1 X
Spacer - 1
Spacer - 1
Circlip ext. inv. 15 - 1
Inner ring int. IM15X20X1 - 1
Washer - 1
Screw - 1
Sealing ring - 1
Kit output AHE3 HAD
J
J3
J3
J2
J1
