346523_04
Series: C
5 / 3210/2012
PARTS LIST
High
Medium
Low
Item Description Part no. Qty Wear
1 CAP 63223 1
2 SPRING 63243 1
3 NEEDLE 63213 1 X
4 TUBE 63233 1
5 O RING 7.65X1.78 40503 1 X
6 PISTON AND CYLINDER 66763 1
7 PEN BODY 63053 1
8 FILTER 66333 1
9 WASHER 44513 1
10 VALVE STEM 68923 1
11 O RING 10.82X1.78 43463 2 X
12 VALVE BODY 68933 1
13 CIRCLIP 68943 1 X
14 VALVE SLIDE G1/8F-G1/8 68913 1
15 WASHER SEAL 9.5X15.4 271533 1 X
16 WASHER SEAL 12.9X20.8 271543 1 X
17 HOSE 05X08.5MM 75902 1
18 SPANNER .42”X .32”A/F OPEN 63533 1
19 LABEL 380923 1
