MAINTENANCE LBB Series Oven Owner’s Manual
54 Version 20
Fan wheel
(spaced
0.25 from
inside top)
Motor
shaft
sleeve
Tinnerman
clip
Motor
mount
Motor
Torx
screw
Torx
screw
Figure 25. Separate fan wheel from fan motor shaft.
