LBB Series Oven Owner’s Manual MAINTENANCE
Version 20 51
Flat washer
Terminal Ring
Flat washer
Hex nut
Lock washer
Insulator
Install terminals as shown to prevent
possible electrical shorts and/or stress
on terminals. Angle tolerance: +/- 15°.
Front View
Side View
72” wire
.
Figure 22. Heater element connections.
18” wire
