Models 1-38, and 1-67 come equipped with an appropriate plug and cord. Models LAC 2-12 and
2-18 must be hardwired to the electric supply using 10 AWG or larger wires suitable for at least
75 °C (167 °F).
4.2.3.1. Wire LAC-8 Models 2-12 and 2-18
For units that must be hardwired or where a power cord is
shipped loose, run the power lines from the rear of the oven to
the front control panel.
1. Run the wire through the clearly marked power cord access port. (Figure 10).
Figure 9. LAC2-18-8 Nameplate.
