Det-Tronics PointWatch Eclipse PIRECL - PIRECL CO₂ MODEL MATRIX AND CONFIGURATION; MODEL AND THREAD TYPE OPTIONS; OUTPUT AND WEATHER PROTECTION OPTIONS; APPROVALS AND CLASSIFICATION TYPES

25 95-86763.1
PIRECL CO
2
MODEL MATRIX
MODEL DESCRIPTION
PIRECL Point Infrared Eclipse Gas Detector
TYPE THREAD TYPE
A 3/4” NPT
B M25
TYPE OUTPUT & MEASUREMENT OPTIONS
3 4-20 mA with HART protocol & RS-485: CO
2
0-2%/vol Full Scale Range
TYPE OPTIONAL OUTPUTS
A HART Communication Port
B HART Communication Port and Relay Board Ex d only
D No Optional Outputs
E Relay Board Ex d only
TYPE WEATHER PROTECTION
1 Weather Baffle with Hydrophobic Filter
TYPE APPROVALS
B INMETRO (Brazil)
C CSA/IECEx
E ATEX/CE/IECEx
TYPE CLASSIFICATION
1 Division/Zone Ex d e
2 Division/Zone Ex d
