DEVICE VARIABLES SUBMENU
1 Process Variables
Selecting this menu item will list all process variables and their values.
These process variables are continuously updated, and include:
1 Gas CO2 2.0% (Gas detected)
2 PV 0.0 Vol% (Primary variable - current gas concentration)
3 Loop current (Loop current in milliamperes)
4 PV % range (Primary variable - percent of range)
5 Range Values (displays upper/lower value and upper/lower sensor limit)
1 PV USL 2.00 Vol% (upper sensor limit)
2 PV LSL 0.00 Vol% (lower sensor limit)
3 PV URV 2.00 Vol% (upper range value)
4 PV LRV 0.00 Vol% (lower range value)
6 PV % range graph (available with graphic option only)
2 Identication
Selecting this menu offers device and HART identification information.
1 Device Info
1 Manufacturer
2 Dev id
3 Model
4 Revision #’s
1 Universal rev
2 Fld dev rev
3 Software rev
2 HART info
1 Tag
2 Long tag
3 Message (Text associated with the field device that can be used by the operator in any way)
4 Date
5 Write protect (This indicates whether variables can be written to the device, or whether commands that
cause actions to be performed in the device can or cannot occur)
6 Final asmbly num
1 Process Variables
2 Identification
