E-8 95-86763.1
DEVICE SETUP SUBMENU
1 Basic Setup
1 Gas CO2 2.0%
2 PV Snsr unit Vol %
3 PV URV 2.00 Vol %
4 Device information
1 Manufacturer
2 Dev id (A number is used to identify a unique field device)
3 Tag
4 Long tag
5 Date
6
Descriptor (Text associated with the field device that can be used by the operator in any way)
7
Message (Text associated with the field device that can be used by the operator in any way)
8
Model
9
Write protect
2 Detailed Setup
1 Gas Type
2 Sensor Information
1 PV USL (Upper sensor limit value defines the maximum usable value for the upper range of the sensor)
2 Active (Output value of the active sensor)
3 Reference (Output value of the reference sensor)
4 Ratio (Ratio of the active sensor over the reference sensor)
5 Absorption % (Gas absorption expressed in percent)
6 Span Factor (Number used in calibrating this specific device)
7 Snsr temp degC (Temperature of the sensor that is making the process measurement)
8 Vol % @ 100% FS (% volume of gas equal to 100% FS)
3 Write Protect
1 Password (A password is required to enable writing to the device)
2 Set Write Protect
–
Disable
–
Enable
–
Change Password
3 Write Protect
1 Basic Setup
2 Detailed Setup
3 Output Condition
4 Review
