Dettson SUPREME - Page 26

11
TABLE 2
Air Flow (CFM) – SUPREME with 1/3 HP motor
0,1 0,2 0,3 0,4 0,5 0,6 0,7
LOW 715 700 690 675 660 650 635
MED-LOW 935 900 870 835 800 770 735
MED-HIGH 1090 1050 1010 970 930 890 850
HIGH 1285 1250 1220 1185 1150 1120 1085
Blower Speed
Static Pressure
The airflow values are expressed in cubic feet per minute (CFM’), rounded to 5 CFM more or less.
These readings were taken with the air filter installed.
TABLE 3
Air Flow (CFM) – SUPREME with 1 HP motor
0,1 0,2 0,3 0,4 0,5 0,6 0,7
LOW 1035 1030 1030 1025 1020 1020 1015
MED-LOW 1315 1300 1285 1270 1255 1240 1225
MED-HIGH 1715 1650 1590 1525 1460 1400 1335
HIGH 1935 1900 1870 1835 1800 1770 1735
Blower Speed
Static Pressure
The airflow values are expressed in cubic feet per minute (CFM), rounded to 5 CFM more or less.
These readings were taken with the air filter installed.
FIGURE 5
Dimensions
DNS-0982 Rev.B
