Torsional vibration damper
TCD 2013 2V W 05-02-01
Removing and installing torsional vibration damper
(V-belt drive)
Standard tools
Removing the torsional vibration damper
● Unscrew all screws (1).
● Remove the torsional vibration damper.
● Visually inspect the components.
1
1
1
© 44436-0
Installing the torsional vibration damper
● Mount the torsional vibration damper.
M10x20-12.9
– without washer
● Tighten screws alternately.
 70 Nm
Note installation position.
The holes in the torsional vibration damper
must match the threaded holes in the V-
belt pulley.
Attention!
The following new screws without washers
must be used when the torsional vibration
damper is removed or changed.
See the spare parts documentation.
© 44437-0
